Measure AC Current

999.9 A

Measure AC Current via iFlex

2500 A

Measure AC Voltage

600.0 V

Measure Continuity

≤ 30 §Ù

Measure DC Current

999.9 A

Measure DC Voltage

600.0 V

Measure Resistance

60k §Ù

Measure Frequency

500 Hz

Work in poorly lit areas

Backlight

Diameter of Measurable Conductor

01.3 in. or 34mm max

Operating Temperature

-14 to 122ºF (10 to 50ºC)

Storage Temperature

-40 to 140ºF (-40 to 60ºC)

Operating Humidity

<90% @ 10 to 30ºC, <75% @ 30 to 40ºC

Operating Altitude

0 to 3000 m

IFlex Size

246 x 83 x 43 mm, (9.685 x 3.267 x 1.692 in.)

Weight

2.5 kg (5.51lbs)

Temperature Coefficient

0.01%ºC (<18ºC or > 28ºC)

Warranty

Three years for electronics
One year for cable and clamp assembly
