Specifications

Function

Range

Resolution

Accuracy

AC Current via jaw

999.9A

0.1A

2% ± 5 digits

AC current via iFlex

2500A

0.1A

3% ± 5 digits

DC current

999.9A

0.1A

2% ± 5 digits

AC Voltage

1000V

0.1V

1.5% ± 5 digits

DC Voltage

1000V

0.1V

1% ± 5 digits

Resistance

60,000 Ω

0.1 Ω

1% ± 5 digits

Frequency

500 Hz

0.1 Hz

0.5% ± 5 digits

True-RMS

Included

Continuity

Included

Hold

Included

Backlight

Included

Min/Max/Avg

Included

Inrush

Included

Wire capacity

750 MCM or 2-500 MCM

Safety rating

CAT III 1000 V, CAT IV 600 V

General Specifications

Diameter of measurable
conductor

1.3" or 34 mm max

Operating temperature

-14 to 122°F (-10 to 50°C)

Storage Temperature

-40 to 140°F (-40 to 60°C)

Operating Humidity

< 90% @ 10 to 30 °C, < 75% @ 30 to 40°C

Operating Altitude

0 to 2000m

Temperature Coefficient

0.01% °C(<18°C or > 28°C)

Size

10.905 x 3.464 x 1.629 in (277 x 88 x 43 mm)

Weight

12 oz. (350g)
