Feature

Range

Accuracy

Voltage DC

0 – 600.0 V

1% ± 5 counts

Voltage AC (True RMS)

0 – 600.0 V

1% ± 5 counts (50/60 Hz)

Current AC (True RMS)

0 – 600.0 A

2.0% ± 5 counts (50/60 Hz)

Current DC

0 - 200.0 µA

1.0% ± 5 counts

Resistance

0 – 9999 Ω

1.5% ± 5 counts

Continuity

<= 30 Ω

Temperature* (Type K Thermocouple)

-10 degree C to 400 degree C (-14 degree F to 752 degree F)

+/- 1.0% + 0.8 degree C (+/- 1.0% + 1.5 degree F) typical

-40 degree C to -10 degree C (-40 degree F to -14 degree F)

+/- 5.0% + 1.5 degree C (+/- 5.0% + 3.3 degree F) typical

Capacitance

1-1000 µF

1.9% ± 2 counts

Mechanical & General Specifications

Weight

1.5 lbs (.7 kg)

Dimensions

10.75” x 4.25” x 2.44” (27.3 cm x 10.8 cm x 6.2 cm)

Battery type

(2) AA Alkaline Batteries
