Type

R

G

Generator

Frequency (Hz)

50

Engine Speed (rpm)

5800/4100(Power Mode/Silent Mode)

Waveform

Square-Wave

AC Output

Maximum Power (W)

1000

Rated Power (W)

900

Rated Voltage (V)

220

230

DC Output

Only for Charging 12V
Automotive Batteries.

Maximum Charging Output = 8.3/4.2A
(Power Mode/Silent Mode)

Insulation Class

B

Engine

Maker

HONDA

Model

GXH50

Type

Air Cooled OHV 4-stroke Gasoline

Displacement (CC)

49.4

Others

L X W X H (mm)

465 X 265 X 380

Dry Weight (kg)

13.6

14.0

Fuel Tank Capacity (liters)

3.8

Sound Level

[dB(A)/7m]

58(1/2 load)

(dB Lwa )

89(3/4 load)

Pilot Lamp

LED

Power Indicator

LED

Oil Alert System

YES

Engine Stop

Interlocking with Fuel Cock

AC

Output

Plug Socket X 1

Protective Device

Control Circuit

DC

Output

Protective Device

Thermal Type Circuit Breaker
