Weighing Capacity

250 g / 101 g

Resolution

0.1 mg / 0.01 mg

Repeatability
(Std. Deviation)

0.1 mg / 0.03 mg

Grams (g)

250 x 0.0001 / 101 x 0.00001

Decimal ounces (oz)

8.82 x 0.00001 / 3.56 x 0.000001

Troy ounce (ozt)

8.04 x 0.00001 / 3.25 x 0.000001

Pennyweight (dwt)

160.8 x 0.0001 / 64.9 x 0.00001

Carat (ct)

1250 x 0.001 / 505 x 0.001

Grains (GN)

3858 x 0.002 / 1559 x 0.0002

Tola (t)

21.43 x 0.00001 / 8.86 x 0.000001

Linearity

± 0.2 mg / 0.1 mg

Stabilization Time

3.5 seconds / 8 seconds

Sensitivity Drift
(10° C-30° C/50° F-86° F)

± 2 ppm / °C
(when automatic self calibration is not used)

Operating Temperature

5° C to 40 ° C
(41° F to 104° F), 85% RH or less

Sensing Method

Flexure Bearing Magnetic Force Motor

Display Type

LCD

Display Refresh rates

5 times/second or 10 times/second

Weighing units and modes

g, mg, oz, ozt, dwt, ct, gn, mm, TL, Ms, t, and percent % and counting PCS

Counting Mode

0.1 mg

10, 25, 50 or 100 pieces

Percent Mode

0.01 g

0.01%, 0.1%, 1%
Depends on the reference mass stored

Standard interface

RS-232C Serial interface with Windows Communication Tools (WinCT)

Optional interface

Optional feature must be factory installed when placing order.  Bluetooth Transmitter range 30 feet.  Ethernet net option is a hot seller to view your balance anywhere on your network.

Calibration

Motorized Internal cal Standard
External cal requires purchase of OPTIONAL
20, 50, 100 or 200g ASTM class 1 cal mass

Weighing Pan

Ø90mm / 3.6 in Stainless Steel

Physical Dimensions

217 (W) x 442 (D) x 316 (H)

8.54 (W) x 17.4 (D) x 12.24 (H)

Breeze Break Dimensions

183 (W) x 148.5 (D) x 251 (H)

7.2 (W) x 5.84 (D) x 9.88 (H)

AC adapter

100, 120, 220, 240 VAC (AC adapter) 50/60 Hz All balances shipped with 120V AC Adapter. For other voltages add $25.00

Power Consumption

Approx. 11VA (supplied by AC adapter)

Warranty

5 years manufacturer's warranty

Net Weight

Approx. 8.2 kg / 18.7 lbs
